ABB CA4-22M 2NO/2NC AF09-AF16 FRONT MOUNT AUXILIARY CONTACT
MFR Part #:Â CA4-22M
SKU #:Â 1270718
Brand:Â ABB
UPC:Â 804325559799
ABB CA4-22M Auxiliary Contact Block, 24/690 VAC, 6 A, 2NO-2NC Contacts
1SBN010140R1122
cUL Listed | CB/CCC/CE/DNV/EAC/RINA Certified | RoHS Compliant
Notice something off about this product?
Product Details
Attributes
Features
Resources
ABB Auxiliary Contact Block, 24/690 VAC, 6 A, 50/60 Hz Frequency, 2NO-2NC Contacts, 4 Maximum Contact Block, Front Mounting, 1200/900 Cycles/hr Operating Cycles, For Use With: AF09 Through AF96 Across the Line Contactors, 46 mm L x 46 mm W x 46 mm H Dimensions
Amperage Rating:6 A
Country Of Origin:Poland
Dimensions:46 mm L x 46 mm W x 46 mm H
Frequency Rating:50/60 Hz
Maximum Contact Block:4
Mounting Type:Front
Number of Contacts:2NO-2NC
Operating Cycles:1200/900 Cycles/hr
Suitable For Use With:AF09 Through AF96 Across the Line Contactors
Voltage Rating:24/690 VAC
- Screw terminals
Product Details
ABB Auxiliary Contact Block, 24/690 VAC, 6 A, 50/60 Hz Frequency, 2NO-2NC Contacts, 4 Maximum Contact Block, Front Mounting, 1200/900 Cycles/hr Operating Cycles, For Use With: AF09 Through AF96 Across the Line Contactors, 46 mm L x 46 mm W x 46 mm H Dimensions
Attributes
Amperage Rating:Â 6 A
Country Of Origin:Â Poland
Dimensions:Â 46 mm L x 46 mm W x 46 mm H
Frequency Rating:Â 50/60 Hz
Maximum Contact Block:Â 4
Mounting Type:Â Front
Number of Contacts:Â 2NO-2NC
Operating Cycles:Â 1200/900 Cycles/hr
Suitable For Use With:Â AF09 Through AF96 Across the Line Contactors
Voltage Rating:Â 24/690 VAC
Features
- Screw terminals
